Haskell on a Horse

Haskell on a Horse (HoH) is a combinatorial web framework for the programming language Haskell. I developed it in 2010, but other responsibilities prevented me from ever really finishing it - at this point I have moved on to other projects.

The project remains interesting for various reasons - there is a coroutine implementation in Control/Arrow/Transformer/Automaton/Monad, the LabeledArrow and MaybeAutomaton classes are unique as far as I know, and the compositional handling of web forms is, as far as I know, more sophisticated than any other system.

If you'd like to browse the code, it is available on github now.

Installing and Using HoH

cabal install on-a-horse
{-#LANGUAGE Arrows, QuasiQuotes, ScopedTypeVariables, NoMonomorphismRestriction #-}
import Web.Horse
import Control.Applicative
import Control.Arrow
import Control.Monad
import Control.Monad.Cont
import Data.Maybe
import Network.Wai.Handler.Warp (run)
import Data.Monoid
import qualified Data.Set as S
import Data.List.Split (splitOn)
import Control.Arrow.Transformer.All
import Text.Pandoc

Atomic Components

An HoH application is built up from atomic components. A component is a complete HoH application all by itself: it can render itself, and respond to input.

ex1 = proc url -> do
    (fo,num::Maybe Integer) <- readForm "enter a number" -< ()
    returnA -< wrapForm fo
No read:

run this as a web app on port 8080 using

main = do
     app <- runHorse ex1
     run 8080 app

Side-by-Side Components

Components can be rendered side-by-side within a page.

ex2 :: HoHMay Url String
ex2 =  proc url -> do
              (fo1, oper) <- enumForm "operation"
                          [("times", (*)),
                           ("plus", (+))] -< ()
              (fo2, x::Maybe Integer) <- readForm "x" -< ()
              (fo3, y::Maybe Integer) <- readForm "y" -< ()
              let result = show <$> (oper <*> x <*> y)
              returnA -< wrapForm $ mconcat [
                           "Calculate a number!",
                           fo1, fo2, fo3,
                           fromMaybe "" result,
Calculate a number!
No read:
No read:

Replacing one Component With Another

Components can be replaced. A call to the arrow throwAuto will replace the nearest enclosing catchAuto. The new component will be called immediately, with no form input.

formSum label fs def = catchAuto $ proc _ -> do
  (fo,f) <- enumForm label fs -< ()
  case f of
    Just f' -> throwAuto -< f'
    Nothing -> returnA -< setFormOut fo def

Note: def is a default value to be used when no form is yet selected.

ex3 :: HoHMay Url String
ex3 = formSum "example to run" [("example 1",ex1),("example 2",ex2)] mempty
      >>> arr wrapForm

A More Complex Example

By combining the techniques above, sophisticated pages can be made with little code.

ex4 = proc url -> do
     (fo,result) <- term "expression" -< ()
     returnA -< wrapForm $ mconcat [fo, "Result:", maybe "" show result, "<br/>"]
       term :: String -> HoHMay () (FormOut, Maybe Integer)
       term label = catchMayAuto $ formSum label
            [("number", number label),
             ("add",oper label "add" (+)),
             ("multiply",oper label "multiply" (*))] (mempty, Nothing)

       number :: String -> HoHErrMay (HoH () (FormOut, Maybe Integer))
                  () (FormOut, Maybe Integer)
       number termLabel = proc () -> do
              fo1 <- linkForm "cancel" (term termLabel) -< ()
              (fo2,x) <- readForm "number" -< ()
              returnA -< (fo1 `mappend` fo2, x)

       oper termLabel label f = proc () -> do
            (fo1) <- linkForm "cancel" (term termLabel) -< ()
            (fo2,x) <- liftError (term "x") -< ()
            (fo3,y) <- liftError (term "y") -< ()
            out <- returnA -< mconcat $ ["<div class=\"oper\">", fo1, label, "<br/>", fo2, fo3]
            returnA -< (out, f <$> x <*> y)


Building Atomic Components

Atomic components should generally use the 'withInput' function. This will add two inputs to an arrow: the first is a unique label for the component, and the second is the current input to the arrow, or Nothing if there is no input. The label should be used as a name in any form input or query parameters. Here is the code for linkForm.

linkForm linkName f = withInput $ proc ((),nm,iname) -> do
              case iname of
                Just _ -> throwAuto -< f
                Nothing -> returnA -< (link linkName nm)

(link "name" "label" produces <a href="?label=1">name</a>)

Handling urls

runHorse sends the URL as the sole argument to the handler. A function, dispatch, is available to construct multi-page applications.

ex5 = proc url -> do
           (dispatch $ staticUrls fourOhFour $
             [("", urls),
              ("ex1", ex1),
              ("ex2", ex2),
              ("ex3", ex3),
              ("ex4", ex4)]) -< (url,url)
example 1
example 2
example 3
example 4
fourOhFour = proc url -> do
               returnA -< "Page not found"
urls = proc url -> do
        returnA -< mconcat [
                     "<a href=\"/ex1\">example 1</a><br/>",
                     "<a href=\"/ex2\">example 2</a><br/>",
                     "<a href=\"/ex3\">example 3</a><br/>",
                     "<a href=\"/ex4\">example 4</a><br/>"

Running the Tutorial

This tutorial is a sort of self-executing markdown (pandoc) file. This is the code to run it.

main = do
  tut <- readFile "tutorial.lhs"
  tmpl <- getDefaultTemplate Nothing "html"
  let pd = readMarkdown def{readerExtensions = S.insert Ext_literate_haskell (readerExtensions def)} tut
  let tut' = writeHtmlString def{
              writerTemplate= either (error . show) id tmpl
              } pd
  let ts = splitOn ("EXA"++"MPLE") tut'
  app <- runHorse $ proc url -> do
         fo1 <- ex1 -< url
         fo2 <- ex2 -< url
         fo3 <- ex3 -< url
         fo4 <- ex4 -< url
         fo5 <- ex5 -< url
         let vals = interleave ts [fo1,fo2,fo3,fo4,fo5]
         returnA -< mconcat vals
  run 8000 app
interleave (x:xs) (y:ys) = (x:y:interleave xs ys)
interleave [] ys = ys
interleave xs [] = xs

-- Jason Priestley, July 26, 2010. (jason @ this domain)
